SENYD BTH1 high-speed synchronous servo motor: 10,000 rpm, 15,000 rpm, 20,000 rpm, 60,000 rpm.

High-Speed Synchronous Servo Motor

SENYD high-speed servo motor provides corresponding solutions for various high-speed testing applications. SENYD high-speed motors have been successfully applied in CNC machine tools, bearing testing, encoder testing, motor rotor testing, and other scenarios.

Permanent magnet brushless servo motor
Standard thermal protection and high-precision sine/cosine encoder feedback
Water cooling design enables high power density and low noise
Power range: 0.75 kW ~ 10,000 kW
High speed capability, up to 60,000 rpm
Features lightweight design, low inertia, and high efficiency

Product Information

High-Speed Synchronous Servo Motor Selection Guide
Motor Type	Series	Power Range	Pole Pairs	Motor Outer Diameter	Max Speed	Max Torque	Encoder Configuration	Cooling Method
Synchronous Servo	BTH103X	0.75kw~4kw	1	88mm	60000rpm	2nm	Resolver encoder	Liquid cooling
	BTH104X	0.74kw~7.5kw	2	108mm	30000rpm	10nm	Resolver encoder	Liquid cooling
	BTH107X	4kw~37kw	2	150mm	24000rpm	50nm	Resolver encoder	Liquid cooling
	BTH109X	7.5kw~60kw	3	200mm	18000rpm	100nm	Resolver encoder	Liquid cooling
	BTH112X	22kw~150kw	3	245mm	12000rpm	300nm	Resolver encoder	Liquid cooling
	BTH113X	20kw~250kw	4	260mm	20000rpm	500nm	Resolver encoder	Liquid cooling
	BTH114X	30kw~110kw	4	268mm	20000rpm	1000nm	Resolver encoder	Liquid cooling
	BTH118X	40kw~200kw	4	380mm	20000rpm	1500nm	Resolver encoder	Liquid cooling
	BTH119X	120kw~1000kw	6	410mm	20000rpm	3000nm	Resolver encoder	Liquid cooling
	With a speed increaser (gearbox) solution, the semi-direct-drive motor can reach: Maximum power: up to 1000 kW Maximum speed: up to 25,000 rpm
