SENYD BTH6 high-power synchronous servo motor, 1.5 MW, 10,000 rpm, for test bench applications.

High-Power Synchronous Servo Motor

SENYD high-power motors are designed to provide direct-drive solutions for various large-scale test benches. At present, we are able to deliver dynamometer systems for the most complex testing applications with power up to 1.5 MW and rotational speeds up to 10,000 rpm. These systems are widely used in new energy vehicle testing, aerospace testing, axle testing, heavy-duty trucks, and construction machinery testing.

Permanent Magnet Synchronous Servo Motor

Customization available, tailor-made solutions
Standard thermal protection with optional high-precision encoder feedback
High power density, compact structure, small size, and lightweight design
Liquid cooling (oil/water) for minimal environmental impact and reliable operation
High rigidity with real-time load response, low energy consumption, and high efficiency

Product Information

High-Torque Synchronous Servo Motor Selection Guide
Motor Type	Series	Power Range	Pole Pairs	Center Height	Max Speed	Torque Range	Encoder Configuration	Cooling Method
Synchronous Servo	BTH625X	30kw~315kw	6	250mm	10000rpm	287nm~2260nm	Resolver encoder	Liquid cooling
	BTH628X	160kw~500kw	6	280mm	8000rpm	1019nm~3008nm	Resolver encoder	Liquid cooling
	BTH631X	160kw~735kw	6	315mm	6000rpm	1528nm~4775nm	Resolver encoder	Liquid cooling
	BTH645X	550kw~1500kw	8	400mm	6000rpm	5253nm~9550nm	Resolver encoder	Liquid cooling

Brand	SENYD SYD
Model	BTH6
Power	1500 KW
Motor Type	IPM rare-earth permanent magnet medium–high power AC servo motor
Insulation Class	F
Feedback Devices	Incremental square-wave or sine-cosine encoder, resolver, absolute encoder
Temperature Protection	PTC thermistor, KTY84 thermistor
Cable Output	Terminal box, PG cable gland, connector
Installation Type	Output shaft flange mounting
Protection Class	IP54, optional IP64, IP65
Cooling	Liquid cooling: 5°C ≤ coolant temperature < 25°C, flow rate ≥ 13 L/min Water (oil) pressure: 2–8 bar Inlet/outlet temperature difference Δt ≤ 5 K
Surface Coating	Gray/Black, matte finish; other colors available upon customer request.
Operating Environment	Ambient temperature: 0 ~ +40°C Relative humidity: 30% ~ 95% (non-condensing) Atmospheric pressure: 86 ~ 106 kPa Altitude: ≤ 1000 m
Storage & Transportation Environment	Ambient temperature: -15 ~ +55°C Relative humidity: ≤ 95% (at 40°C) Atmospheric pressure: 86 ~ 106 kPa
