SYD High and Low Temperature Servo Motor 55 Series

SENYD servo motors are a high-performance solution designed for operation in harsh high- and low-temperature environments. The motor design can be customized according to specific customer requirements.

High-efficiency neodymium-iron-boron (NdFeB) permanent magnets are used inside the motor. The application of high-quality magnetic materials, together with a specially designed stator and rotor structure, is a key factor enabling high torque output and high power density.

SENYD servo motors are widely used in environments with high humidity, desert climates, extreme heat, severe cold, icing conditions, freezing conditions, and other extreme temperature environments, ensuring stable and reliable equipment operation.

Main Technical Specifications
Ambient temperature: -40°C to +80°C
Rated power: 100 W to 17 kW
Rated speed: 3000 rpm
Feedback system: built-in resolver or absolute encoder
Winding configuration: various customized options available according to customer requirements
Power supply voltage: 28 V DC to 380 V AC
